Page 2
13
60 x 60 x 20 MM SERIES
AFB
DIMENSIONS DRAWING
P & Q CURVE
(AT RATED VOLTAGE)
MOUNTING PANEL CUTOUT
Bearing Type
Ball Bearings
Material
Impeller & Frame : Plastic (UL 94V-0)
Lead Wires :
UL 1007 AWG #24 OR Equivalent
Red Wire Positive (+)
Black Wire Negative (-)
Weight : 56g (1.98 oz)
*
*
*
*
* Function type is optional.
The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
Noise is measured in anechoic chamber in free air, one meter from intake side.
All readings are typical values at rated voltage.
Specifications are subject to change without notice.
*
*
*
*
LABEL
UNIT:
(INCH)
mm
mm
(INCH)
UNIT:
http://www.deltaww.com
*
Operating
Voltage
Range
MODEL
Rated
Voltage
Maximum
Air Flow
Speed
Maximum
Air Pressure
Noise
PART NO. REV. FUNCTION VDC VDC Amp Watt R.P.M.
CFM mmH
2
O IN H
2
O dB-A
AFB0612VHD
-A
-R00 / -F00
12
7.0 to 13.8
0.19
2.28
5400
0.823
29.06
8.72
0.343
41.0
AFB0612SHD
-A
-R00 / -F00
12
7.0 to 13.8
0.28
3.36
6000
0.911
32.17
10.41
0.410
43.0
AFB0612EHD
-A
-R00 / -F00
12
7.0 to 13.8
0.31
3.72
6600
0.997
35.21
12.29
0.484
45.0
OUTLET SIDE
INLET SIDE
Input
Power
Input
Current
