Gas Price 5-3
Display Operation
The controller will then list the “Current Function,” if it is Gas Price you can
continue, otherwise at the next frame: “Current Function? Press Set Function” you
need to press <
Clear/Set Function > and use the <
↑↓>
to select Gas Price.
Note: Press the <
Clear/Set Function > key quickly to enter the function mode. If you
miss this step, unplug the power to the DataMaster controller and start again.
Use the following table as a guide to startup procedures.
LCD Screen Action
CURRENT FUNCTION
GAS PRICE Power is provided to the DM100 through the
serial cable or through the wall pack
transformer, either directly or by way of the j-
box/signal converter.
This display appears briefly.
CHANGE FUNCTION?
PRESS SET FUNCT
This message appears next on the screen.
If “GAS PRICE” was shown on the bottom line
of the LCD during startup, do nothing. The
controller will automatically default to previous
Gas Price settings. (The controller will
remember the last function used, so you should
only have to do this with a new controller or
switching between DataMaster displays.)
If a function other than “GAS PRICE” was
shown on the bottom line of the LCD during
startup, press the <SET FUNCTION> key while
the second LCD prompt is displayed.
You only have 1 or 2 seconds to push it. If you
miss it, unplug the power and try again.
SELECT FUNCTION
GAS PRICE
↓↑
Press the arrow up or down keys<
↑↓> until the
gas price option is shown. Press the <ENTER>
key to accept.
Note: The actual Gas Price values will not be displayed on the DataMaster 100 LCD
screen because these values are kept in the display itself.
