Maintenance and 4-13
Troubleshooting
Digit, 18" 7-segment, red, w/ faceplate 0A-1192-2227
Digit, 18" 7-segment, amber, w/ faceplate 0A-1192-2228
Digit, 24" 7-segment, red, w/ faceplate 0A-1192-2231
Digit, 24" 7-segment, amber, w/ faceplate 0A-1192-2232
Digit segment, 24" red, vert 0P-1192-0204
Digit segment, 24" red horiz 0P-1192-0205
Digit segment, 24" amber, vert 0P-1192-0218
Digit segment, 24" amber horiz 0P-1192-0219
Digit, 24" 9 /
10
red, w/faceplate 0A-1192-2359
Digit, 24" 9 /
10
amber, w/faceplate 0A-1192-2360
Digit, 36" 7-segment, red, hinged 0A-1279-0195
Digit, 36" 7-segment, amber, hinged 0A-1279-0196
Digit segment, 36" red, vert 0P-1192-0208
Digit segment, 36" red horiz 0P-1192-0209
Digit segment, 36" amber, vert 0P-1192-0222
Digit segment, 36" amber horiz 0P-1192-0223
Digit, 48" 7-segment, red, hinged 0A-1279-0181
Digit, 48" 7-segment, amber, hinged 0A-1279-0182
Digit segment, 48" red, vert 0P-1192-0212
Digit segment, 48" red horiz 0P-1192-0213
Digit segment, 48" amber, vert 0P-1192-0226
Digit segment, 48" amber horiz 0P-1192-0227
Digit segment, 60" red, vert 0P-1192-0281
Digit segment, 60" red horiz 0P-1192-0280
Digit segment, 60" amber, vert 0P-1192-0283
Digit segment, 60" amber horiz 0P-1192-0282
Digit, 24", 36”, 48”, 60”
9
/
10
red, pc board 0P-1192-0232
Digit, 24", 36”, 48”, 60”
9
/
10
amber, pc board 0P-1192-0233
Indicator, 2" red, pc board (used in 18" and 24" displays) 0P-1192-0228
Indicator, 2" amber, pc board (used in 18" and 24" displays) 0P-1192-0229
Indicator, 4" red, pc board (used in 36" and 48" displays) 0P-1192-0244
Indicator, 4" amber, pc board (used in 36" and 48" displays) 0P-1192-0245
Indicator, 4" red w/ face plate (used in 36" and 48" displays) 0A-1192-2434
Indicator, 4" amber w/ face plate (used in 36" and 48" displays) 0A-1192-2435
