There are several versions of the PCI20U ARCNET NIM. Three models sup-
port traditional ARCNET 2.5 Mbps di-pulse transceivers. The PCI20U-CXS
supports coaxial star or point-to-point configurations facilitated by the use of
active hubs. The PCI20U-CXB supports coaxial bus configurations while the
PCI20U-TB5 supports twisted pair bus configurations using RJ-45 connectors.
Both bus topology products usually do not require active hubs. Four models
also support EIA-485 networks and both standard mode and backplane mode
are supported. The PCI20U-485 (backplane mode) and PCI20U-485D (non-
backplane mode) support DC-coupled operation. The PCI20U-4000 (back-
plane) and PCI20U-485X (non-backplane) support AC-coupled operation.
SPECIFICATIONS
Environmental
Operating temperature:
0°C to +60°C
Storage temperature: –40°C to +85°C
Data Rates
PCI20U-CXB, -CXS, -TB5 2.5 Mbps
PCI20U-485
, 10 Mbps, 5 Mbps, 2.5 Mbps, 1.25 Mbps,
625 kbps, 312.5 kbps, 156.25 kbps
PCI20U-4000, -485X 10 Mbps, 5 Mbps, 2.5 Mbps, 1.25 Mbps
Dimensions Shipping Weight
2.50" x 4.72" 1 lb. (.45 kg)
(64 mm x 120 mm)
I/O Mapping
Requires 16 bytes of I/O space for COM20022 controller
Interrupt Lines
Supports PCI INTA
Compatibility
PCI20U series NIMs are fully compatible with all of Contemporary Controls
(CC) ARCNET products and PCI Bus computers.
Regulatory Compliance
CE Mark
; CFR 47 Part 15 Class A
Power Requirements
Model +5 V +3.3 V
PCI20U-CXB
PCI20U-CXS
PCI20U-TB5
PCI20U-485X
PCI20U-4000 400 mA 30 mA 20 mA
PCI20U-485D
PCI20U-485
-485D
V I/O
400 mA 30 mA 20 mA
400 mA 30 mA 20 mA
400 mA 30 mA 20 mA
400 mA 30 mA 20 mA
400 mA 30 mA 20 mA
400 mA 30 mA 20 mA
