PARTS LIST
FIREBOX
LMFP33PR AND LMFP33NR
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 28 of this manual.
KEY
NO. PART NUMBER DESCRIPTION QTY.
1 101357-01 Top Outer Casing 1
2 ** Outer Casing 1
3 ** Right Front Side 1
4 ** Left Front Side 1
5 098304-01 Phillips Pan Head Screw, #10-16 x .38 9
6 104239-01CK Top Front Louver 1
7 101712-03 Firebox Hood 1
8 ** Firebox Support 2
9 099230-02 Shoulder Screw 4
10 ** Firebox Top 1
11 101346-01 Outer Base 1
12 ** Firebox Wrapper 1
13 101514-01 Cover 1
14 M11084-26 Hex Screw, #10-16 x .38 45
15 104237-01CK Bottom Louvered Door 1
16 101727-02 Screen Assembly 1
PARTS AVAILABLE — NOT SHOWN
101386-02 Louvered Door Hinge 2
101784-01 Magnet Catch 2
102307-01 Strike Plate 2
** Not a field replaceable part.
