Breakout Panel

Revision 2

Connectors and Switches

MN/UB530.IOM

2–5

2.2.1.2

IDR Interface (J1)

Signal Function

Name

Pin #

Ground GND

1,

2

TX octet output

8K TXO–A

4

8K

TXO–B

5

TX data

8K TXD–A

37

8K

TXD–B

38

TX clock

8K TXC–A

21

8K

TXC–B

22

RX octet

8K RXO–A

6

8K

RXO–B

7

RX data

8K RXD–A

39

8K

RXD–B

40

RX clock

8K RXC–A

23

8K

RXC–B

24

Send data

SD–A

34

SD–B

18

Receive data

RD–A
RD–B

36
20

External clock

EXC–A

35

EXC–B

19

Backward alarm 1 output

BWO1–C

8

BWO1–NO

41

BWO1–NC

25

Backward alarm 2 output

BWO2–C

9

BWO2–NO

42

BWO2–NC

26

Backward alarm 3 output

BWO3–C

10

BWO3–NO

43

BWO3–NC

27

Backward alarm 4 output

BWO4–C

11

BWO4–NO

44

BWO4–NC

28

Backward alarm input

BWI–1

12

BWI–2

13

BWI–3

14

BWI–4

15

ADPCM1 audio input

A1I–A

45

A1I–B

29

ADPCM1 audio output

A1O–A

46

A1O–B

30

ADPCM2 audio input

A2I–A

47

A2I–B

31

ADPCM2 audio output

A2O–A

48

A2O–B

32

Demodulator fault

DF–COM

16

DF–NO

50

Deferred maintenance alarm

DMA

17
