CDS-100 Diversity Switch MN-CDS100
Appendix A Revision 1
A-9
App. A
FIG
CEFD
CABLE P/N
DESCRIPTION
USED FOR
( DATA INTERFACE TYPE)
USED WITH CDS-100
REF Ch. 5
FIG
A-14 CA/WR10522-1 Cable – 1:1 ‘Y’ Splitter, (2X) DB-15M  DB-15F, 5” G.703 Balanced CDM-570/A, CDM-570L/AL 5-30
A-15 PP/SC3523 Cable Assy – RoHS-Compliant, HSSI ‘Y’ Splitter, (2X) HD-50M  HD-50F, 3” HSSI
CDM-710G/L 5-36
CDM-710 5-41
CDM-700 5-45
A-16
PP/CPS2A12501 Cable Assy – RoHS-Compliant, Optical Coupler, 7’ Type ‘SC/UPC’ Connectors OC-3 Single-Mode
CDM-700 5-47
PP/CPM6A1250 Cable Assy – RoHS-Compliant, Optical Coupler, 7’ Type ‘SC/UPC’ Connectors OC-3 Multi-Mode
