Controls, LEDs and Connectors
RTM-ATCA-F120-OPT Installation and Use (6806800G29D) 51
3.2.2.2.1 10 GBit Base Interface Uplinks
These cages can be equipped with standard optical SFP+ connectors for 10 Gigabit
connections and support Ethernet connections in compliance with the IEEEE 802.3ak
standard.
During the qualification testing of the RTM, the following SFP+ models were used:
 10Gb/s 850nm Multimode Datacom SFP+ Transceiver (FTLX8571D3BCL). Orderable via
Artesyn P/N: 5806802A01
 RoHS-6 Compliant 10Gb/s 10km Single Mode Datacom SFP+ Transceiver
(FTLX1471D3BCL). Orderable via Artesyn P/N: 5806803A01
These modules passed all tests sucessfully without incidents. They are also listed in the Artesyn
Embedded Technologies sales configurator. When using SFP+ modules, we recommend to use
these models.
The SFP+ modules can be installed/removed both while the RTM is powered and non-powered.
The presence and also the type of SFP+ modules is automatically detected.
The following table shows which switch MIB OID each cage corresponds to.
3.2.2.2.2 1 GBit Base Interface Uplinks
The four cages for 1 GBit connections can be equipped with standard SFP connectors for
copper and optical connections.
The attached Ethernet switch supports only 10GBit connections on these ports, i.e. 1 GBit
SFP modules are not supported.
Table 3-4 Base Channel 10 GBit Uplink Connectors - Port - MIB OID Assignment
Face Plate Label MIB OID Ethernet Type
BIX XG1 ..1.25 10 GBit
BIX XG2 ..1.26 10 GBit
