ACS-2210A User Manual 9
BIOS AMIBIOS
LVDS 1 x 18/24 bit LVDS output connector
SDVO 1 x SDVO Pin header for internal
(Expansion: SDVO to CRT,SDVO to LVDS,SDVO to
HDMI/DVI)
Storage 1 x SATA Connector
1 x mSATA Connector
Network 1 x RJ-45 1000Mbps LAN Intel 82574L
USB
4 x USB 2.0 stack port for external
2 x USB 2.0 Pin header for internal
Serial
1 x RS232 port, DB9 connector for external (COM3),
pin 9 w/5V/12V/Ring select
1 x RS232/422/485 select header for internal (COM1)
Battery Support CR2477 Li battery by 2-pin header
Audio Support Audio via Realtek ALC662 HD audio decoder
Support Line-in, Line-out, MIC by J2 pin header
Expansion Bus 1 x mini-PCI-express slot (full size)
Support USB 2.0 Device
Expansion
Ports
(J2)
1 x USB 2.0 Pin header for internal
2 x RS232 header for internal (COM2,COM4)
1 x SD Card
1 x PS/2 KB/MS pin header
1 x Audio
8 x GPIO
Power
Management
DC9V~32V input
1 x 2-pin power input connector
Front I/O by 2x5-pin header
Power on/off switch
Reset switch
Power LED status
HDD LED status
WLAN LED status
Watchdog
Timer
Software programmable 1 – 255 second by Super I/O
External I/O
port
2 x COM Port (COM1,COM3)
4 x USB 2.0 Ports (stack)
