ARCHMI-8XX Series User Manual 34
Pin# Signal Name
1 VBAT
2 Ground
6. SW1（NC）:
(2.0mm Pitch 2x2 Pin Header), Reserve.
7. BAT2（NC）:
(2.0mm Pitch 1x8 Wafer Pin Header), Reserve.
8. LED3/LED4（NC）:
LED3: Reserve.
LED4: Reserve.
9. DC_IN1:
(5.08mm Pitch 1x3 Pin Connector), DC9V~36V System power input connector.
Pin# Power input
1 DC+9V~36V
2 Ground
3 FG
Model DC_IN1
SBC-7111-E3845-2G 180°Connector
SBC-7111-E3845-4G 180°Connector
SBC-7111-N2930-2G 180°Connector
SBC-7111-N2930-4G 180°Connector
SBC-7111-E3815-2G 180°Connector
SBC-7111-E3845P-2G 45°Connector
SBC-7111-E3845P-4G 45°Connector
10. BT1/BT2:
Power on/off button, They are used to connect power switch button. The two
pins are disconnected under normal condition. You may short them
temporarily to realize system startup & shutdown or awaken the system from
sleep state.
