Analog Way OPS200 Programmer's Guide User Manual
Page 36
36
Group
Name
CmdResp Description
Read
/
Write
Min
Value
Max
value
Default
value
Values
Index #1
Index #2
PE_BORDER_SIZE_V
bV bV
Border V size
Rd/Wr0
127
10
Unit = pixels
0 = Current
preset
1 = Next preset
2 = Previous
preset
3 = Memory
Preset 1
4 = Memory
Preset 2
5 = Memory
Preset 3
6 = Memory
Preset 4
0 = Background
Frame for output
1
1 = Background
Frame for output
2 in matrix mode
2 = Background
Layer for output 1
3 = Pip 1 Layer
for output1
Background
Layer for output 2
in matrix mode
4 = Pip 2 Layer
for output1
6 = Logo 1
7 = Logo 2
8 = Audio Output
1
9 = Audio Output
2
PE_OPENING_TRANSITION
oT oT
Layer opening transition type
Rd/Wr0
4
2
0 = Cut
1 = CleanCut
2 = Fade
3 = Slide (associée à 1 trajectoire)
4 = Wipe (associée à 1 trajectoire)
0 = Current
preset
1 = Next preset
2 = Previous
preset
3 = Memory
Preset 1
4 = Memory
Preset 2
5 = Memory
Preset 3
6 = Memory
Preset 4
0 = Background
Frame for output
1
1 = Background
Frame for output
2 in matrix mode
2 = Background
Layer for output 1
3 = Pip 1 Layer
for output1
Background
Layer for output 2
in matrix mode
4 = Pip 2 Layer
for output1
6 = Logo 1
7 = Logo 2
8 = Audio Output
1
9 = Audio Output
2
