ZMOTION ® Intrusion Detection Development Kit
User Manual
Installing the FTDI USB to Serial Driver
Observe the following steps to install the FTDI USB to Serial Driver.
1. Make sure that the USB cable is not plugged into the ZMOTION Development Board.
2. Navigate to the ZMOTIONS200ZCOG Software and Documentation installation di-
rectory and double-click the
CDM20802_Setup.exe
file to start the driver installation.
The installation process will begin, and will appear similar to the following code state-
ments:
32-bit OS detected

\dpinstx86.exe

Installation driver

FTDI CDM driver installation process completed.

3. When the installation is complete, plug the USB cable into the ZMOTION Develop-
ment Board.
4. If driver installation was successful,
USB Serial Port (COMx)
should appear in the list
displayed in the Device Manager’s
Ports (COM & LPT)
interface.
To open the Device Manager on Windows 7 systems, launch the Start menu, enter
Device Manager
in the
Search program and files
field, and press the Enter key.
To open the Device Manager on earlier Windows systems, navigate to the following
filepath:
Start
→
Control Panel
→
System
→
Hardware
→
Device Manager
→
Ports
(COM &LPT)
.
Downloading and Running the Sample Project
Sample projects are included in the ZMOTIONS200ZCOG Software and Documentation
directory. Ensure the folders are not set to
Read Only
by right-clicking the folder and
selecting properties. Deselect the
Read Only
attribute and click
OK
. Make sure you apply
changes to this and the other subfolders when prompted.
In this example, we reference the
ZMOTION_Intrusion_Demo
project; however, the
steps that follow will apply to any additional project.
At this point you should have downloaded ZDS II and the SmartCable USB driver on to your
computer. If you haven’t yet done so, revisit the beginning of this Download and Install the
ZDSII Software and Documentation section before proceeding.
1. Open ZDS II and select
File
→
Open Project
, then navigate to the project folder
labeled
ZMOTION_Intrusion_Demo
.
2. Open the
ZMOTION_Intrusion_Demo.zdsproj
project. When you first receive
your kit, this project is already loaded into the ZMOTION MCU. Right-click within the
Note:
