Industrial Ethernet Extender
7
Introduction
The Ethernet Extender provides one channel for Ethernet over existing
voice grade copper wire. It can be used as a stand-alone device or with a
standard 19” chassis.
Product Overview
Product Features
One 10/100BaseT/TX(TX) Ethernet port with RJ-45 connector
Auto negotiation of speed and duplex mode on TX port
Auto MDIX on TX port
Complies with IEEE 802.3 10BaseT and IEEE 802.3u 100BaseTX
standards
One Ethernet Extender port with RJ-11 connector
Ethernet Extender port auto senses the speed of
1/3/5/10/15/20/25/30/40/50Mbps
One switch for configuring Ethernet Extender local or remote mode
Status LEDs
External AC to DC power adapter
Used as a stand-alone device or with a chassis
Hot-swappable when used with a chassis
Packing List
When you unpack this product package, you will find the items listed below.
Please inspect the contents, and report any apparent damage or missing
items immediately to our authorized reseller.
The Ethernet Extender
User’s Manual
AC to DC Power Adaptor
