HIGH EFFICIENCY DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-12
2.1.5 BK1814 Primary Components
(cont.)
ITEM
PART #
DESCRIPTION
1 823-7554
Frypot
(BK50)
* 823-6997
Frypot
(BK60)
2
►►►
See Orifices, Section 2.2
3
See Additional Components and Controllers, Section 2.3
*
810-0703
Tube, Pilot Gas Supply,
1
⁄
4
" x 17½" (one-piece gas line)
4 230-6887
Diffuser
(Baffle)
Assembly
5
►►►
See Drain Components, Section 2.4
6 810-3356
Burner,
High
Efficiency
Cast
7 220-5152
Burner
Mounting
8 200-8748
Heat
shield
9
See Additional Components and Controllers, Section 2.3
* 810-0691
Vent
Tube
10
231-2060
Side Panel, Left Side (unit exterior)
*
231-6259
Side Panel, Left Side BK RAM Inner
11
232-2060
Side Panel, Right Side (unit exterior)
*
232-6259
Side Panel, Right Side BK RAM Inner
12
Back
Panels
220-6434
60/50 BK60/50/RAM/60 (use 220-6432 for RAM/60 - RAM on right)
220-7150
50/60 BK60/RAM/50/60 (use 220-7151 for 60/RAM - RAM on left)
220-6270
BK160
220-6754
BK260
220-7268
BK60/50/60
230-6427
RAM Back Cover with cutout for receptacle
13 823-7515
Joiner
Strip
14
Top Caps
108-0971
BK60/50 (BK1814 - 60/50/RAM/60)
108-1590
BK50/60 (BK1814 - 60/RAM/50/60)
108-0975
BK60/160
108-3606
BK260
108-1750
BK60/50/60
15
Flue Caps
230-6268
BK60/50 (BK1814 - 60/50/RAM/60)
230-6431
RAM/60 (BK1814 - 60/50/RAM/60)
230-7143
60/RAM (BK1814 - 60/RAM/50/60)
230-7142
BK50/60 (BK1814 - 60/RAM/50/60)
230-8800
BK160
230-6705
BK260
230-7238
BK60/50/60
16
Door, Left or Right
106-4309
BK60
106-7542
BK50
17 210-8077
Handle
* 810-2346
Magnet,
Door
* 230-7192
Hinge,
One
Piece
18
Basket
Hanger
823-7773
BK60/50 or BK50/60 (BK1814 - 60/50/RAM/60 or 60/RAM/50/60)
823-7770
BK160 or RAM/60 (BK1814 - 60/50/RAM/60)
823-7774
60/RAM (BK1814 - 60/RAM/50/60)
823-7771
BK260
823-7772
BK60/50/60
19
810-2280
Caster, Plate-mount 5" with Brake
*
106-7649
Cordset, 120V 10’ Power
*
807-5003
Receptacle, RAM 15A 125V
*
108-2582
Relay, Control Assy BK1814/HD50 includes 807-4114 and wire harness
* 812-2185SP
Relay,
Time
Delay
* Not illustrated.
