HIGH EFFICIENCY DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-10
2.1.4 Y/KSCF/C/HC Primary Components
(cont.)
ITEM PART # DESCRIPTION
1 823-6138 Frypot – S/S (YSCFHC 14)
* 106-9637 Frypot – S/S (YSCFHC 18)
* 823-6367 Frypot – S/S (Y/KSCF/C/HC 18) India without hooks
* 823-7879 Frypot – S/S (Y/KSCF/C/HC 18) India with hooks
2 ►►► See Orifices, Section 2.2
3 See Additional Components and Controllers, Section 2.3
* 810-0705 Tube, Pilot Gas Supply, 1 ⁄
4
" x 23" (one-piece gasline)
* 810-0703 Tube, Pilot Gas Supply, 1 ⁄
4
" x 17½" (one-piece gasline)
4 230-4900 Diffuser Assembly (use 230-6888 for 8 row burner) (use 230-7711 for India)
5 ►►► See Drain Components, Section 2.4
6 810-3356 Burner, High Efficiency
* 810-2151 Burner, Left
* 810-2149 Burner, Center
* 810-2150 Burner, Right
7 220-5152 Burner Mounting (use 200-2738 for India)
8 200-8748 Heat shield
9 See Additional Components and Controllers, Section 2.3
* 810-0691 Vent Tube
10 231-2060
Side Panel, Left Side (unit exterior) (use 221-3272 for India) (use 231-8145 for SS
318G) (use 221-8141 318G Painted)
11 232-2060
Side Panel, Right Side (unit exterior) (use 222-3272 for India) (use 232-8145 for
SS 318G) (use 222-8141 318G Painted)
12 220-1828 Back Panel
13 210-1355 Joiner Strip
13a 823-6922 Joiner Strip
13b 823-7924 Joiner Strip (India slotted for hooks)
14 Top Caps
106-7984 214
106-7985 314
106-7669 218 (use 106-9625 for India)
106-9785 318
15 Flue Caps
823-6292 214
823-6300 314
230-1833
218 (use 823-6880 for India before Feb. 11) (use 823-7875 for India after Feb.
11)
823-6974 318 ( use 230-1890 for YSCFHC318G)
16 106-8511 Door, left or right
17 810-3335 Handle, Push-in
* 810-2346 Magnet, Door
* 230-4998 Hinge, One Piece
18 810-2793 Basket Hanger, Double
18a 810-2794 Basket Hanger, Double Wireform
18b 230-8002 Basket Hanger, Double Keyholed (India)
230-8757 Basket Hanger, Triple Keyholed
19 810-0356 Caster, Plate-mount 5" without Brake (use 826-1138 for India)
20 810-0357 Caster, Plate-mount 5" with Brake
* 106-7649 Cordset, 10’ Power
21 810-2411 Leg, Single Bolt Mount (black)
* 810-3169 Leg, 4 Bolt Mount, Package (4 per set) (use 810-3168 for India)
22 823-3248 Leg, Single Bolt Mount Support Assembly
* Not illustrated.
