HIGH EFFICIENCY DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-4
2.1.2 Decathlon HD60/63 Primary Components
(cont.)
ITEM PART # DESCRIPTION
1 106-9632 Frypot - S/S
* 106-9634 Frypot - S/S (Single HD60 without filtration)
* 823-5742SP Frypot - S/S (Single HD60 without filtration, Red Robin)
* 106-9638SP Frypot - S/S (Single HD63 without filtration)
* 823-6314 Frypot - S/S (Single HD63 without filtration, Red Robin)
2 ►►► See Orifices, Section 2.2
3 See Additional Components and Controllers, Section 2.3
* 810-0705 Tube, 1 ⁄
4
" x 23" Pilot Gas Supply (one-piece gasline)
* 810-0703 Tube, 1 ⁄
4
" x 17½" Pilot Gas Supply (one-piece gasline)
* 810-0703 Tube, Pilot Gas Supply, 1 ⁄
4
" x 17.50" (one-piece gasline)
4 230-1431 Diffuser Assembly
5 ►►► See Drain Components, Section 2.4
6 810-3356 Burner, High Efficiency
7 220-5152 Burner Bracket
8 200-8748 Shield, Burner Heat
9 See Additional Components and Controllers, Section 2.3
* 810-0691 Vent Tube
10 231-2311SP Side Panel, Left Side
11 232-2311SP Side Panel, Right Side
* 221-2737 Side Panel, Left Side (Filter Ready)
* 222-2737 Side Panel, Right Side (Filter Ready)
* 823-5744 Side Panel, with Splash Panel (660/363/663)
12 Cabinet Back (One-piece)
220-1851 x1 (Single)
220-1828 x2 (2-battery)
220-3702 x2, without Deflector (2-battery)
220-4518 x1, without Deflector (3-battery)
13 210-3017 Joiner strip
14 Top Cap
106-5434 x1 (Single)
106-5953 x2 (2- and 6-battery)
106-6080 x3 (3- and 6-battery)
106-4683 x4 (4- and 6-battery)
15 Flue Cap
230-3078 x1 (Single)
230-1833 x2 (2-battery)
230-1890 x3 (3-battery)
230-1891 x4 (4-battery)
230-1890 x3 (6-battery)
230-1891 x4 (6-battery)
16 106-4309SP Door Assembly, left or right
17 210-8077 Handle, Door
* 810-2346 Magnet, Door
* 230-4998 Hinge, One-piece
* Not illustrated.
