HIGH EFFICIENCY DECATHLON SERIES GAS FRYERS

CHAPTER 2: PARTS LIST

2-2

Each section is labeled by size (e.g., D50) and parts are not interchangeable between different sized fryers. The parts in this manual
are for use on Common Cabinet style fryer.

If you have any questions, call the Frymaster and Dean 24-Hour Service Hotline, 1-800-551-8633.

2.1.1 Decathlon HD50 Primary Components

ITEM

PART #

DESCRIPTION

1

826-3009

Frypot - S/S

2

►►►

See Orifices, Section 2.2

3

See Additional Components and Controllers, Section 2.3

* 810-0705

Tube,

1

4

"

x 23" Pilot Gas Supply (one-piece gasline)

* 810-0703

Tube,

1

4

"

x 17½" Pilot Gas Supply (one-piece gasline)

4 230-4900

Diffuser

Assembly

5

►►►

See Drain Components, Section 2.4

6 810-3356

Burner,

High

Efficiency

7

220-5287

Bracket, Burner Mounting

8

200-9063

Shield, Burner Heat

9

See Additional Components and Controllers, Section 2.3

10

231-2060

Side Panel, Left Side

11

232-2060

Side Panel, Right Side

12

Cabinet Back

*

220-1847 x1

(Single)

*

220-1806

x2 (2-battery)

*

220-1838

x3 (3-battery)

13

823-5932 Joiner

Strip

14

Top Cap

106-5433

x1

(Single)

106-5955 x2

(2-battery)

106-5956

x3

(3-battery)

106-6333

x4

(4-battery)

106-7631

x5

(5-battery)

15

Flue Cap

230-1848

x1

(Single)

230-1812

x2

(2-battery)

230-1841

x3

(3-battery)

230-1875

x4

(4-battery)

230-2434

x5

(5-battery)

16

106-7542SP

Door Assembly (Left or Right)

17

210-8077 Handle,

Door

*

810-2346

Magnetic Catch, Door

* 230-4998

Hinge,

One-piece

18

Basket Lifts

210-1595

Single (SCFHD50, 823-4075 with deflector)

210-3131

Double (SCFHD50, 823-4074 with deflector)

19

810-0356

Caster, Plate-mount, 5" without Brake

*

826-1117

Caster Kit, Plate-mount, 5" without Brake (includes mounting hardware)

20

810-0357

Caster, Plate-mount, 5" with Brake

*

826-1118

Caster Kit, Plate-mount, 5" with Brake (includes mounting hardware)

*

810-0944

Caster, Plate-mount, 3" with Brake

*

810-1494

Caster, Plate-mount, 4" without Brake

*

106-7649

Cordset, 10' Power

21

810-2411

Leg, Single Bolt Mount (black)

*

810-3169

Leg Package, 4 Bolt Mount (4 per set)

22 823-3248

Leg

Support

Assembly

* Not illustrated.
