Page 8 Presentation Switchers, Inc.
Pre-Drill Mounting Holes
Locating the Switcher Locating the Switcher
Locate the switcher under the table toward the center line of the table. Ensure switcher is far
away from poten al contact with people’s legs or knees.
WARNING: Keep product away from poten al contact with human legs, knees, and other
body parts. A PS510 is made of metal and can harm people if struck with suffi
cient force.
Pre-Drill Mounting Holes As Shown Pre-Drill Mounting Holes As Shown
1. Using a 3/32” drill (for so wood) or 7/64” drill (for hardwood), drill each hole approximately
5/8” in depth.
2. Using #2 Phillips screw driver, fasten all 6 screws.
Center Line of
PS510
