iii
P/N: 4809658
©2006 Paxton Automotive
All Rights Reserved, Intl. Copr. Secured
23MAR06 v1.0 UnivSBMCarb(4809658v1.0)
Proper installation of this system requires general automotive mechanic knowledge
and experience. Please browse through each step of this instruction manual prior to
beginning the installation to determine if you should refer the job to a professional
installer/technician. Please call Paxton Automotive for installers in your area.
*** NOTE ***
The following carbureted base system support parts are not included as part of the system but
are available from Paxton Automotive:
1. Carburetor enclosure P/N: 8PM205-060/068 (Included in 1201851/-P)
2. Optional fuel line/fittings kits for the carburetor. They include custom bent stainless steel
lines, billet -8 bulkhead adapter with fuel pressure port and plug, -8/-6 junction TEE, alu-
minum swivel hose ends and USCG approved fuel hose.
• #8M110-020 Holley 4150 series (w/dual metering blocks), SS fuel line kit.
• #8M110-030 Demon series, SS fuel line kit.
3. Carburetor air diffuser, straightens airflow into the carburetor for improved response/drive-
ability.
• #8M011-001 Ø5.75" x 2.50" tall carburetor air diffuser, stainless steel.
4. Supercharger discharge assembly (for use with 8M205-060/-068)
P/N: 4PCX112-030 . (Included in 1201851/-P)
5. Compressor bypass valve and flange (require on applications exceeding 5 psig boost) (P/N:
8D204-010 included in 4PCX112-030, can be purchased seperately). Contact the technical
department to determine the proper valve selection for the application.
• #8D201-010 Race Bypass Valve
• #8D004-052 Race Bypass Valve weld-on flange (aluminum)
• #8D004-055 Tube, aluminum Ø1.5" x 1" (for welding 8D004-052 to round tube)
• #8D103-001 Mondo Race Bypass Valve
• #8D003-052 Mondo Race Bypass Valve weld-on flange (aluminum)
• #9AT200-090 Tube, aluminum Ø2.0" x specify length (for welding 8D004-052 to
round tube)
6. Boost referenced ignition/timing retard systems.
• #5A001-009 HI-6 TR Ignition System “CRANE”
• #5A001-001 Stand alone ignition retard “MSD” (not an ignition enhancer)
7. Supercharger pulleys: (Contact technical department for proper appication match)
• Paxton #4MA031-312: 3.12" Diameter 10-rib driven pulley
• Paxton #4MA031-333: 3.33" Diameter 10-rib driven pulley
• Paxton #4MA031-347: 3.47" Diameter 10-rib driven pulley
• Paxton #4MA031-360: 3.60" Diameter 10-rib driven pulley
• Paxton #4MA031-387: 3.87" Diameter 10-rib driven pulley
• Paxton #4MA018-041: 6.00" Diameter 10-rib drive (crank) pulley
Items to be supplied by installer/end user:
• Carburetor with mechanical secondaries (4150 Holley/Barry Grant MD style)
• High performance fuel pump (boost referenced)
Optional: Aftermarket blow-through style carburetor bonnet.
