Paxton Superchargers Mustang Air/Air Cooler - Manual (Page 7)

P/N: 4809638
©2003 Paxton Automotive
All Rights Reserved, Intl. Copr. Secured
10NOV03 v2.0 99-01 MusGT(4809638 v2.0)
1-1
Section 1
INITIAL PREPARATION AND REMOVAL
1.1 INITIAL PREPARATION AND REMOVAL
A. Remove the plastic clips(4) that hold the
grill cover in place. (See Fig. 1-a.)
Fig. 1-a
CLIPS
B. Remove the hood latch support screw using
a T-30 torx bit. (See Fig. 1-b.)
Fig. 1-b
SCREW
C. Place car on lift or jackstands.
D. Remove the screw at the bottom of the sup-
port bar. (See Fig. 1-c.)
Fig. 1-c
Fig. 1-d
E. Remove the power steering cooler line sup-
port screw. (See Fig. 1-d.)
