Appendix C: ICEB 6100 Carrier Board
Appendix C: ICEB 6100 Carrier Board
Specifications
Expansion
• 1 PCI-104 socket
• 2 Mini PCI Express socket
- 1 PCIe interface for WLAN module
- 1 PCIe + USB interface for 3.5G module
Storage
• One SATA 2.5” HDD bay
• One internal Type I/ II CompactFlash socket
I/O Interfaces - Front
• 4 SMA-type mounting holes for WLAN and HSDPA
• 1 power button
• 1 reset switch
• 1 SIM card socket
• 1 USB 2.0
• 4 LEDs for Standby, HDD, WLAN/HSDPA and GPO
• 1 line-out
• 1 mic-in
I/O Interfaces - Front
• 4 SMA-type mounting holes for WLAN and HSDPA
• 1 power button
• 1 reset switch
• 1 SIM card socket
• 1 USB 2.0
• 4 LEDs for Standby, HDD, WLAN/HSDPA and GPO
• 1 line-out
• 1 mic-in
Dimensions
• 260mm(W) x 176mm(D) x 50mm(H)
10.24”(W) x 7”(D) x 1.97”(H)
