Appendix B: ICES 270 COM Express CPU Module
•	 LVDS
 - LFP (local flat panel) LVDS interface
 - Supports single/dual channel for 18 bit
 - Panel in Nexcom LVDS: 1366 x 768 tested
•	 SDVO
 - One SDVO B down to CD connector
Network
•	 LAN chip: Realtek PCI Express GbE 8111C-GR x 1
•	 Supports PXE
•	 Supports WOL
Audio
•	 HD configurable audio bus interface
Storage
•	 2 x SATA II (3.0 Gbps)
•	 1 x IDE (33/66/100)
I/O
•	 Reset switch
•	 8 GPIO lines (GP
I 0~3 and GPO 0~3), CMOS Level (0/3.3V)
•	 I2C interface / SMbus interface
•	 USB 2.0 x 8
•	 PATA
PCI/PCIe
•	 32-bit PCI V2.3 interface
•	 PCI express x 1
 - 5 Lanes (via dip switch for 5x1 or 1x1+ 1x4)
Fan Connector
•	 1 x 3-pin fan connector (reserved, 90 degree, 12V )
Super I/O
•	 LPC interface
BIOS
•	 Award System BIOS 6.0
•	 SPI ROM
•	 Plug & Play support
•	 Advanced Power Management and Advanced Configuration & Power
Interface support
Power Supply
•	 +12Vdc, 3.3V battery, +5Vsb power input
•	 Supports both AT and ATX power supply mode
System Monitor
•	 Monitors 4 voltages, 2 temperatures and 1 fan speed
 - 4 voltages (+3.3V, +5V, +12V, Vcore)
 - 2 temperatures (CPU and one external temperature sensor)
Power Management
•	 ACPI 2.0 compliant with battery support
•	 Supports Suspend to RAM (S3)
