Installing the PCI-104 Module
1. Locate for the PCI-104 slot on the board.
PCI-104 slot
Mounting stud
2. Position the PCI-104 module above the slot then press it down firmly
until it is completely seated in the slot. This will at the same time align
the module’s mounting holes to the mounting studs on the board.
Mounting
stud
Mounting
hole
PCI-104
module
