Appendix A: Watchdog Timer

a

PPendIx

a: W

atChdog

t

Imer

WDT Programming Guide

PEAK 886VL2 Watch Dog Function Configuration Sequence Description:

Start

Step1. See “SetupWDT” procedure
#Setup Watchdog Timer Environment

Step2. See “TimeBaseWDT” procedure
#Initial Watchdog Timer.
Users can select second or minute.

Step3. See “TimeCountWDT” procedure
#Set Watchdog Timer Time-out Value.
Users can set time-out value.

Step4: See ExitSetup procedure
#Exit Setup Environment

End
