Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. 28 PEAK 886VL2 User Manual
Chapter 3: BIOS Setup
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enable/Disable Intel (R) Active
Mangement Technology BIOS
Extension.
Note: iAMT H/W is always
enabled.
This option just controls the
BIOS extension execution. If
enabled, this requires addtional
firmware in the SPI device. Intel AMT [Enabled]
BIOS Hotkey Pressed [Disabled]
MEBx Selection Screen [Disabled]
AMT Configuration
This section is used to configure Active Management Technology (AMT)
options.
Intel® AMT
Enables or disables Intel® Active Management Technology.
BIOS Hotkey Pressed
Enables or disables BIOS hotkey press.
MEBx Selection Screen
Enables or disables MEBx selection screen.
