Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. 8 PEAK 886VL2 User Manual
Chapter 2: Jumpers and Connectors
Jumpers
CMOS Connector
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP7
Pin Settings
1-2 On Normal
2-3 On Clear CMOS
1-2 On: default
Pin Definition
1 NC
2 RTCRST#
3 GND
AT/ATX Pin Header
Connector type: 1x3 3-pin header, 2.00mm pitch
Connector location: JP4
Pin Settings
1-2 On ATX
2-3 On AT
1-2 On: default
Pin Definition
1 AT_PWRBT#
2 PCH PWRBT#
3 EXTAL PWRBT#
1 3 1 3
