Chapter 3: UEFI Setup Utility
3.3.1 CPU Configuration
CPU Ratio
Use this item to change the ratio value of this motherboard.
Intel SpeedStep Technology
Intel SpeedStep technology is Intel’s new power saving technology.
Processors can switch between multiple frequencies and voltage points to
enable power saving. The default value is [Enabled]. Configuration options:
[Enabled] and [Disabled]. If you install Windows
® VistaTM / 7 / 8 and want
to enable this function, please set this item to [Enabled]. This item will be
hidden if the current CPU does not support Intel SpeedStep technology.
Intel Turbo Boost Technology
Use this item to enable or disable Intel Turbo Boost Mode Technology.Turbo
Boost Mode allows processor cores to run faster than marked frequency in
specific conditions. The default value is [Enabled].
Long Duration Power Limit
Use this item to configure long duration power limit in watts. The default
value is [Auto].
Long Duration Maintained
Use this item to configure time window which the long duration power is
maintained. The default value is [Auto].
Short Duration Power Limit
Use this item to configure short duration power limit in watts. The default
value is [Auto].
Primary Plane Current Limit
Use this item to configure the maximum instantaneous current allowed for
the primary plane. The default value is [Auto].
Advanced Main
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Adjust CPU Turbo Ratio, CPU
Core Frequency will be Ratio *
BCLK
Max CPU Speed
Min CPU Speed
Processor Cores
Intel HT Technology
IntelVT-X Technology
Intel SMX Technology
64-bit
CPU Ratio
Intel SpeedStep Technology
Intel Turbo Boost Technology
Long Duration Power Limit
Long Duration Maintained
Short Duration Power Limit
Primary Plane Current Limit
Secondary Plane Current Limit
Active Processor Cores
Enhanced Halt State(C1E)
CPU C3 State Support
CPU C6 State Support
Package C State Support
CPU Thermal Throtting
3000 MHz
1600 MHz
4
Not Supported
Supported
Supported
Supported
[Auto]
[Enabled]
[Enabled]
Auto
[Auto]
Auto
Auto
Auto
[All
[Enabled]
[Enabled]
[Enabled]
[Auto]
[Enabled]
Save & Exit H/M Monitor Boot Security
Intel ® Core(TM) i5-3550S CPU @ 3.00GHz
Please note that enabling this function may reduce CPU voltage
and lead to system stability or compatibility issues with some
power supplies. Please set this item to [Disabled] if above issues
occur.
