Specifications & Package Contents
~ 4 ~
Specifications & Package Contents
Model Name ASP-88
Technical
Role of usage True 8x8 matrix
HDMI compliance HDMI 1.4a
HDCP compliance Yes
Video bandwidth Single-link 225MHz [6.75Gbps]
Video support 480i / 480p / 720p / 1080i / 1080p60 8-12 bit color
Audio support Surround sound (up to 7.1ch) or stereo digital audio
ESD protection
[1] Human body model: ±19kV [air-gap discharge] & ±12kV [contact discharge]
[2] Core chipset: ±8kV
PCB stack-up 4-layer board [impedance control — differential 100!; single 50!]
Input 8x HDMI + 1x RS-232 + 1x USB + 1x 3.5mm
Output 8x HDMI
HDMI input selection Push button / IR remote / RS-232 / USB
IR remote control Electro-optical characteristics: " = 25#; carrier frequency: 36-40kHz
HDMI connector Type A [19-pin female]
RS-232 connector DE-9 [9-pin D-sub female]
USB connector* Standard type-B [square shape]
3.5mm connector IR socket for IR receiver
DIP Switch
[SW1-SW8]: 2-pin for EDID & audio/video settings
[SW Main]: 4-pin for normal operation or firmware update
Mechanical
Housing Metal enclosure
Dimensions
[L x W x H]
Model 290 x 440 x 44mm [11.4” x 1’5” x 1.7”]
Package 400 x 530 x 130mm [1’4” x 1’9” x 5”]
Weight
Model 3250g [7.2 lbs]
Package 5700g [12.6 lbs]
Fixedness 1RU rack-mount with ears
Power supply AC Power 100-240V
Power consumption 60 Watts [max]
Operation temperature 0~40#C [32~104#F]
Storage temperature -20~60#C [-4~140#F]
Relative humidity 20~90% RH [no condensation]
Package
Contents
1x ASP-88
2x 1RU rack-mount ear
1x IR remote control
1x Installation CD
1x UL AC C13 power cord
1x User Manual
*USB or RS-232 control must be connected either one at a time. Connecting both types of
cables may cause command confusion.
