~ 16 ~
c. PREVIEW presets
1. Press the PREVIEW button on the front panel.
2. Press the LOAD button.
3. Select the preset profile number to load the corresponding mapping and press the
respective button.
4. Press the LOAD button or PREVIEW button to escape PREVIEW presets state
d. PREVIEW INPUT/OUTPUT mapping status
1. Press the PREVIEW button on the front panel.
2. Check mapping by push INPUTS or OUTPUTS buttons.
3. Press the PREVIEW button to escape PREVIEW status.
Step 1 & 4
Step 3
Step 2 & 4
Step 1 & 3
Step 2
