1.2 Technical Specification
ESML3-FL2-D4
Switching
Mode Store-and-forward
Switching rate 148810pps
Max filtering rate 148810pps
System switching bandwidth 5.6Gbps
MAC address table 8k
Ports
Serial Data
Physical Port 3.81 phoenix wiring terminal
Error rate of data transmission 0
Electrical characteristic
In line with 3 wires RS232 & 2 wires
RS485
Software flow control XON/XOFF, default: no flow control
Serial baud rate 50-230.4kbps, default: 9.6kps
Data bit 5,6,7,8 default: 8 bit
Check bit
None, Even, Odd, Space, Mark, default:
None
Stop bit 1,1.5,2 default: 1
Embedded gateway of serial port
Supports
ARP, TCP/IP, UDP, ICMP, BOOTP, DHCP,
SNTP, TFTP, Telnet, HTTP, SSL, SSH
1.0/2.0, SNMP V1/V2/V3
Flash memory 8Mbytes
SDRAM 64Mbytes expandable to 128Mbytes
Copper
Physical port 3 x shielded RJ45
RJ45 port
10Base-T/100Base-TX, Auto-
negotiation
Standard IEEE 802.3
Transmission distance <100m
Fiber
Optical power
>-13dbm(SM) >-20dbm(MM)
Receive sensitivity <-28dbm(SM) <-35dbm(MM)
Wavelength
1310nm(SM) 1310 nm(MM)
Transmission distance
0 - 40Km(1310nm SM)
0 - 5Km(1310 MM)
Connector SC
Transmission rate 125Mbps(100M)
Console
Physical interface Shielded RJ45
Interface standard In line with RS232 standard (3 lines)
Interface rate 9600bps
