D-Link DES-2218 User Manual
Page 75
DES-2218 Ethernet Switch User’s Guide
Cables and Connectors
63
M o d e m
(D C E , D B -2 5 )
C o n s o le P o rt
(D C E , D B -9 )
- (9 )
R X D (2 )
T xD (3 )
D T R (4 )
S G (5 )
D S R (6 )
R T S (7 )
C T S (8 )
D C D (1 )
R X D (3 )
T xD (2 )
D T R (2 0 )
S G (7 )
D S R (6 )
R T S (4 )
C T S (5 )
D C D (8 )
Remote (Modem) Connection to 25-Pin Serial Port
