PARTS LIST
GAS COMPONENTS
MODELS TD100, TD102, TD104 AND TD110
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts, page 15.
KEY
NO. PART NO.
DESCRIPTION qTY.
1 118893-01 Light Post Burner Bracket 1
10373-01 Top Light Burner Assembly 1
3 118904-01 Lightpost Burner Flex Line 1
4 10570-01 Ignitor Electrode Kit 1
5 118906-0 Thermocouple 1
6 119091-01 Lightpost Main Burner 1
7 118911-01 Main Burner Orifice 1
8 11947-01 Orifice Nut 1
9 118913-01 Main Burner Tube 1
10 09871-11 Radiant Ignitor Wire 1
11 118868-0 Main Burner Control Valve 1
1 113793-01 Manual Shutoff Valve 1
13 118914-01 Valve Flex Line 1
14 099393-0 Valve Knob 1
15 098508-01 Control Nut 1
16 11993-01 Outlet Fitting 1
17 118907-01 Outlet T Fitting 1
18 111435-01 Electronic Ignitor 1
19 118909-01 Outlet Elbow 1
0 118896-01 Lightpost Component Plate 1
1 100898-01 Thermocouple Nut
PARTS AvAILABLE - NOT SHOWN
119111-01 Hardware Blister Pack 1
119093-01 Regulator and Hose Assembly 1
103158-01 Magnetic Door Catch
119110-01 Propane Tank Retention Chain 1
10574-01 Retention Hook
118990-0 Control Position Decal, English 1
118990-03 Control Position Decal, Spanish/French 1
118990-04 Control Position Decal, Eng/Spn/Frn 1
118988-0 Warning Decal 1
118989-0 Model Data Decal 1
100639-13 Caution Decal 1
11997-01 Regulator Label 1
