PARTS LIST
CABINET ASSEMBLY
MODELS TD100, TD102, TD104 AND TD110
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts, page 15.
KEY
NO. PART NO.
DESCRIPTION qTY.
1 118890-01 Lightpost Top Cap • 1
118890-0 Lightpost Top Cap • • 1
118891-01 Deco Light Shroud Assembly, Mission • •
118891-0 Deco Light Shroud Assembly, Ornate •
3 11889-01 Lightpost Top • 1
11889-0 Lightpost Top • • 1
4 118885-01 Lightpost Panel • 4
118885-0 Lightpost Panel • • 4
5 118884-01 Lower Burner Housing Top • 1
118884-0 Lower Burner Housing Top • • 1
6 118887-01 Reflector Right/Left • • •
7 118888-01 Reflector Top • • • 1
8 118889-01 Reflector Bottom • • • 1
9 118883-01 Lower Burner Housing • 1
118883-0 Lower Burner Housing • • 1
10 11888-01 Cabinet Base Top • 1
11888-0 Cabinet Base Top • • 1
11 119004-01 Lower Screen • • • 1
1 118900-01 Front Lower Burner Grate, Mission • • 1
118900-0 Front Lower Burner Grate, Ornate • 1
13 118905-01 Base Cabinet Door • 1
118905-0 Base Cabinet Door • • 1
14 118881-01 Cabinet Base • 1
118881-0 Cabinet Base • • 1
15 118899-01 Lightpost Base • • • 1
16 118901-01 Lightpost Base Weight • • • 1
17 11890-01 Base Foot • • • 4
18 119005-01 Upper Screen • • • 4
19 118849-01 Wheel • • •
* 11943-01 Accessory Cover (not shown) • 1
TD100, TD1
10
TD102 TD104
* Available as accessory for models TD100, TD10 and TD110.
