2.2 Supported Formats
The table below summarizes all supported inputs and outputs available on the S2H-30.
Supported Input(s) Supported Output(s)
SD-SDI: NTSC, PAL (SMPTE
259M-C 4:3 or 16:9, SMPTE
259M-C 4:3 or 16:9)
HD-SDI: all HD formats
(SMPTE 274, SMPTE296,
SMPTE372, SMPTE 424M 3G
SDI, 2K).
HDMI: Supported output formats are listed
below:
640x480 = VGA
720x480i = 480i
720x480p = 480p
720x576i = 576i
720x576p = 576p
800x600 = SVGA
1280x720 = 720p
1024x768 = XGA
1366x768 = WXGA
1280x1024 = SXGA
1400x1050 = SXGA+
1680x1050 = WSXGA+
1920x1080i = 1080i
1920x1080p = 1080p
1920x1200 = WUXGA
