4. CAREFULLY rotate the cutterhead by turning the belt

by hand. The knives should just touch the straight
edge.

5. If the knife is high or low at either end, slightly

turn the four screws (D) Fig. 41, in the knife
locking bar clockwise to loosen using the
wrench (E) supplied. Then adjust the height of
the knife by turning the knife raising screws (F)
Fig. 42, counterclockwise to lower and clockwise to
raise the knife.

NOTE: If the knife is to be lowered it will be necessary to
wear protective gloves and carefully push down on the
knife with a piece of scrap wood after screws (F) have
been turned.
6. Repeat these procedures for adjusting the remaining

two knives.

9. As a final check, run a piece of work slowly over the

knives for 6 to 8 inches. The wood should rest firmly
on both tables as shown in Fig. 45, with no open
spaces under the finished cut.

8. If the knives are set too high, the work will be gouged

at the end of the cut, as shown in Fig. 44.

7. If the knives are set too low, the result will be as

shown in Fig. 43, and the finished surface will be
curved.

KNIVES
SET TOO LOW

WORK

OUT-FEED

TABLE

IN-FEED TABLE

CUTTER

Fig. 43

KNIVES
SET TOO HIGH

IN-FEED TABLE

WORK

OUT-FEED

TABLE

CUTTER

Fig. 44

WORK

IN-FEED TABLE

CUTTER

OUT-FEED

TABLE

KNIVES AT
CORRECT HEIGHT

Fig. 45

B

C

A

Fig. 40

F

F

Fig. 42
