DVR User Manual
13
Basic configuration includes three sub menus: system, date & time and DST.
4.1.1 System
Step 1: Enter into MenuSetupBasic System interface. Refer to Fig 4-3:
Fig 4-3 Basic Configuration-System
Step 2: In this interface you can setup the device name, device ID, video format, max network
users, VGA resolution, language and so on. The definitions for every parameters display as
below:
Device Name: The name of the device. It may display on the client end or CMS that help user
to recognize the device remotely.
Device ID: This ID is used to map the DVR with IR remote controller and speed dome
cameras.
Video Format: Two modes: PAL and NTSC. User can select the video format according to
that of camera.
Password Check: If this option is enabled, the user would need to input the user name and the
password for performing corresponding operations.
Show System Time: If selected, the current time will be displayed during live monitoring.
Max Online Users: To set the max number of concurrent user logins in the DVR.
Video Output: The resolution of live display interface, range from: VGA800*600,
VGA1280*1024 and CVBS.
Note
：
Switching between VGA and CVBS will change the menu output mode. Please
connect to relevant monitor.
Language: Setup the menu language.
Note: After changing the language and video output, the device needs to login again.
Logout After (Minutes): A user can setup the screen interval time (30s, 60s, 180s, 300s). If
