6.OSD - Patterns, Tours 6.OSD - Zones and Privacy Mask
PATTERNS
Pattern
Pattern records the user’s operation steps on
performing PTZ control and stores as a track.
The G65 and G70 Series can record up to 4
tracks with max. 180 sec. each.
PATTERN NUMBER:
PROGRAM PATTERN:
RUN PATTERN:
CLEAR PATTERN:
EDIT PATTERN LABEL :
Selects the pattern number,
from 1 to 4
Starts recording the
pattern when selected. you can perfome PTZ
movement for recording and shall not exceed 180
sec. Press IRIS-OPEN to save the track.
Starts the current pattern
Delete curretn pattern.
Sets the name for
current pattern.
PATTERN NUMBER 1
PROGRAM PATTERN
RUN PATTERN
CLEAR PATTERN
EDIT PATTERN LABEL
BACK
EXIT
Tour
Tour is an auto-run through selected preset
points with definable pause time. A tour can
store up to 32 presets points.
TOUR DWELL:
TOUR PRESETS:
RUN TOUR:
pause time for every stop on
the preset points. selectable between 000-
255(s).
press IRIS-OPEN Key on the
keyboard device to enter the preset point
selection. Move the joystick with up and down
to select the preset points by number and save
the setting with IRIS-OPEN key. with IRIS-
CLOSE key you can move to the previous
selection. If a select point has the value 0, all
the following presets points will be ignored.
Starts the tour and exit the OSD
menu.
EDIT TOUR
TOUR DWELL 001
00-00-00-00-00-00-00-00
00-00-00-00-00-00-00-00
00-00-00-00-00-00-00-00
00-00-00-00-00-00-00-00
RUN
TOUR
BACK
EXIT
Zone
You can define the zones in the whole PT range up
to
with individual label. When the
display setting “Zone Label” is activated, the
label will be displayed on the operation screen.
The definition of the zones should not be
overlapped.
up to 8 zones
ZONES NUMBER:
SET LEFT LIMIT:
SET RIGHT LIMIT:
CLEAR ZONE:
EDIT ZONE LABEL :
Current zone selection
Left limit of the current zone
Right limit of the current zone
Delet the current zone
change the laben of current
zone.
ZONES
ZONES NUMBER 1
SET LEFT LIMIT
SET RIGHT LIMIT
CLEAR ZONE
EDIT ZONE LABEL
BACK
EXIT
Some products may not be available in your country, please contact our distributor for more details Some products may not be available in your country, please contact our distributor for more details
17 18
ENGLISH
TIME RUNNING
DAY SUN
TIME CHANNEL 1
START TIME
00:00
END TIME 00:00
RUNNING NONE
BACK
EXIT
Time Running
You can set up the timer to start a function like
preset, tour or pattern. Each day can be set 4
action.
AUTO TRACKING
DAY SUN
STATE ON
START TIME 00:00
END TIME 00:00
SENSITIVE LOW
TRACKING-ZOOM OFF
SET LEFT LIMIT
SET RIGHT LIMT
BACK
AUTO TRACKING
Auto-Tracking can seach people or object with
high speed and low light performance.
DAY: set current day
STATE: activate AUTO-TRACKING on this day
START TIME: set the time for activation
END TIME: set the time for stop the tracking
SENSITIVE: set the sensitivity for the detection
SET LIMIT: set the max. angle for the tracking.
