Remote log – D-Link Wireless ADSL2/2+ 4-port Ethernet Router DSL-2640U User Manual

Page 66

background image


65


Select from the list of NTP (Network Time Protocol) time servers. Then select the

time zone that you are in and click on Apply to save.

Remote Log

The Log dialog allows you to view and configure the log. To view the log, click on
the View System Log button.


Below is the System Log screen which shows the date/time of the log, the facility

that was logged, the severity level and the log message. Click on Refresh to view
any new information that is logged.

NOTE:

When you

click on the View System
Log
button, the System
Log
screen that you access
will be located under the

Status section (see screen
on left). To return to the
previous screen to

configure system log,
remember to click on the
Tools tab (located on top
row) first and then click on

Remotelog.

System Log when log
mode is ENABLED

System Log when log
mode is DISABLED
