INSTALLATION
2
EN T
<
<
EN T
<
<
1
2
Main Serial Interface
Auxiliary Serial Interface
* P.S. (Presence Sensor) connected to External Trigger/PS input.
Figure 54 – Pass Through Connection for Fieldbus Models
2.7.3 RS232
The RS232 mas
n a
network consisti
The Sla e scan
e
scanner transmi .
All messages wi
he master scanner is connected to the Host PC on the main RS232 serial interface through
e C-BOX 100 (20 mA C.L. can be used if the INT-30 accessory is installed).
In RS232 Master/Slave connections the External Trigger signal is unique to the system
(single P.S.).
Master/Slave
ter/slave connection is used to integrate a DS6300 reader (all models) i
ng of different scanners not provided with a Lonworks interface.
ners use RS232 only on the main and auxiliary interfaces. Each slav v
ts the messages received by the auxiliary interface onto the main interface
ll be transferred towards the master.
T
th
NOTE
The DS6300 master/slave scanner model (DS6300-10X-010 only),
working as Master in an RS232 network, may be simultaneously
connected to a Lonworks network consisting of DS6300 slave scanners.
Be careful when assigning the slave address, since the number of the first
Lonworks slave must be a progressive number with respect to the
address number defined for the last slave scanner of the RS232 network.
For example, if the RS232 network consists of Slave 1 and Slave 2, the
address to be assigned to the first Lonworks slave scanner will be Slave 3
(not Slave 1).
Remote Host
Gryphon
DS6300
C-BOX 100
DS4600A
P.S.* P.S.*
DS4600A
C-BOX 100
C-BOX 100
PWR-120
2 1 2 1
AUX
CAB-601X
Fieldbus
work
P.S.*
Net
