19
6.4 Adding iRadio Stations
The Naim Radio Guide web site enables iRadio stations not
included in the standard NAC-N 172 XS list to be added for
playback by your NAC-N 172 XS. To access the web site
and add stations follow the steps below.
• With a computer connected to the same network as
the NAC-N 172 XS, browse to
http://naim.vtuner.com
• Enter the identification (ID) of your NAC-N 172 XS
where requested on the web page. The ID is the
unit’s MAC address. This can be found via the
following NAC-N 172 XS menus:
Setup > Factory
Settings > System Status > MAC .
Note: You can register a username and password so that
the MAC address is not required on any subsequent visit.
• To add stations follow the My Added Stations link and
provide the information required. Click on the arrow
to complete the procedure.
• The added station will then be visible on the Naim
Radio Guide home page.
• To access the stations from the NAC-N 172 XS, select
the iRadio input then select
Added Stations .
6.5 Storing Radio Presets
When the handset store key is
pressed the display will show a
menu that enables confirmation
of the preset store and options to
rename or delete a stored preset.
Selecting the store option opens
a menu that enables the preset
to be stored in one of the forty
locations. Scroll to the desired
location and press the
ok/list key.
Selecting Rename Preset
opens a menu that provides
the opportunity to rename a
previously stored station. Scroll
to the preset to be renamed
and press the
ok/list key to
open a text entry screen. Use
the handset
numeric/text keys
in text entry mode to select characters. Press the ok/list
key to save the new preset name. See Section 3.7 for a full
description of text entry.
Selecting Delete Preset opens a preset list menu. Scroll to
the desired preset and press the ok/list key.
Note: Preset operations (store, rename or delete) are
not possible directly from list mode. The store key must
be pressed when in normal play mode to access these
options.
NAC-N 172 XS Multi-mode Radio
Store Station 1/40
4 1 Empty
2 Empty
3 Empty
4 Empty
Rename Preset 3/4
1 BBCR3 FM
2 BBCR4 FM
4 3 91.15MHz FM
4 BBCR1 FM
Browse Presets 3/20
1 BBCR3 FM
2 BBCR4 FM
4 3 91.15MHz FM
4 BBC 6Mus DAB
Presets 1/3
4 Store 91.15MHz
Rename Preset
Delete Preset
6.6 Using Radio Presets
To select a preset press the
handset
preset key to open the
Browse Presets menu. Scroll to the
desired preset and press the ok/
list key.
Note: The Browse Presets menu
displays presets stored across all three NAC-N 172 XS
radio modes (FM, DAB, iRadio). Selecting a preset from
a radio mode other than the one currently selected will
automatically switch NAC-N 172 XS to that mode.
Note: It is possible for an internet radio station stored
as a preset to be “off-line” and be unavailable when
subsequently selected. If this occurs an alert message will
be displayed.
Note: Pressing the preset key will display the preset list
regardless of the currently selected input.
