11
4.2 The Language Menu
The Language setup menu
enables the NAC-N 172 XS
user interface language to be
changed. Enter setup mode
and use the handset
ok/list
key
to select
Language
. Use the
handset
up
(
5
) and
down
(
6
) and
ok/list
keys to select a
language. Exit setup mode by pressing the
exit
key.
4.3 The Inputs Menu
The Inputs setup menu enables
a variety of parameters to be
specified for each
NAC-N 172 XS internal source and
external input. These parameters
define how control of
NAC-N 172 XS inputs behaves.
The options available for each
are described in the following
sections. Three parameters are
common to all inputs:
Enabled:
Switches the input on or
off and displays or hides any associated menus.
Name:
Enables user specified names to be attached to
inputs. Use the handset to enter text.
Input Trim
: Enables the relative level of each input to
be adjusted so that each is of an approximately equal
volume. Adjust using the handset
6
or
5
key.
4.3.1 FM Input
Parameter Options
Enabled:
Yes / No
Name:
User definable
Input Trim:
±10dB
Seek Lock:
Medium / High.
Sets the FM signal strength required for
the NAC-N 172 XS tuner to identify an FM
station.
NAC-N 172 XS Setup
4 NAC-N 172 XS Setup
Once your NAC-N 172 XS is installed with mains power and all external connections
made, it can be switched on and set up for use.
The degree to which you modify your NAC-N 172 XS’s default settings will depend upon
the uses to which you put it and the extent to which you use its capabilities. It may be that
you have no need to modify the default settings at all, however we would encourage you
to read this section of the manual in order that you gain a full understanding of
NAC-N 172 XS’s capabilities. The following paragraphs describe each NAC-N 172 XS
setup menu in turn starting with the setup home menu.
Enter the NAC-N 172 XS setup mode by pressing the handset setup ( ) key or pressing
and holding the front panel ok/list key. Navigate around the setup menus using the front
panel or handset arrow keys and make selections using the ok/list key. Exit setup by
pressing the exit keys.
4.1 The Setup Home Menu
The NAC-N 172 XS setup home
menu provides access to ten
setup menus. The function of
each menu is as follows:
Language:
Enables the
NAC-N 172 XS
user interface language to be changed.
Inputs:
Enables various parameters for each
internal and external input to be
configured.
Analogue
Configures NAC-N 172 XS analogue
Outputs:
output settings.
Headphones:
Configures NAC-N 172 XS headphone
output options.
Network Settings:
Configures NAC-N 172 XS network
connection settings.
Front Display:
Configures NAC-N 172 XS display features.
Clock & Alarm:
Configures clock and alarm.
Handset Keys:
Enables NAC-N 172 XS inputs to be
assigned to
specific handset keys. Also
enables configuration of the handset
navigation (
3456
) keys.
System
Enables system automation to be
Automation:
configured.
Factory Settings:
Enables interrogation of NAC-N 172 XS
status, deletion of all user presets and
return to factory default settings.
Each of the ten setup menus is described in detail in the
following sections. Use the handset
up
(
5
) and
down
(
6
)
and
ok/list
keys to select a setup menu.
Setup 1/10
4
Language
Inputs
Analogue Outputs
Headphones
Language 1/7
4
English
Français
Deutsch
Italiano
Select Input
1/14
4
FM
DAB
iRadio
UPnP
FM 1/4
4
Enabled: Yes
Name:
FM
Input Trim:
0
Seek Lock:
Medium
FM 4/4
Enabled:
Yes
Name:
FM
Input Trim:
0
4
Seek Lock:
Medium
