FEATURES
High efficiency: 89% @ 5V/ 15A
Size: 58.4mm x 22.8mm x 9.2mm
(2.30”x0.90”x0.36”)
Industry standard pin out
18~75V extremely wide 4:1 input range
Fixed frequency operation
Input UVLO, Output OCP, OVP and OTP
2250V isolation
Basic insulation
No minimum load required
SMD and through-hole versions
ISO 9001, TL 9000, ISO 14001, QS 9000,
OHSAS 18001 certified manufacturing
facility
UL/cUL 60950-1 (US & Canada)
Recognized, and TUV (EN60950-1)
Certified
CE mark meets 73/23/EEC and 93/68/EEC
directives.
OPTIONS
Positive On/Off logic
Short pin lengths available
SMD pin
Delphi Series E36SR
, 75W Eighth Brick Family
DC/DC Power Modules: 18~75V in, 5V/15A out
The Delphi Series E36SR Eighth Brick, 18~75V input, single output,
isolated DC/DC converter is the latest offering from a world leader in
power systems technology and manufacturing — Delta Electronics, Inc.
This product family operates from an extremely wide 18~75V input range
and provides up to 75 watts of power in an industry standard eighth brick
footprint and pinout. With creative design technology and optimization of
component placement, these converters possess outstanding electrical
and thermal performances, as well as extremely high reliability under
highly stressful operating conditions. All models are fully protected from
abnormal input/output voltage, current, and temperature conditions. The
Delphi Series converters meet all safety requirements with basic
insulation.
APPLICATIONS
Telecom / Datacom
Wireless Networks
Optical Network Equipment
Server and Data Storage
Industrial / Testing Equipment
DATASHEET
DS_E36SR05015_01042008
