6
ENVISION 2 NKW 50Hz REVERSIBLE CHILLER INSTALLATION MANUAL
General Installation Information cont.
70
16
165
76.2
121
133
89
12.7
6.35
Number
Compatible
With
Spring
Color
Rated
Capacity
Rated
Deflection
Isolator
Constant
Adjustment
Bolt [in x mm]
Qty
IS-325-01 030-045 Brown 147 kg 31 mm 4.72 kg/mm 1/2 x 89 4
IS-750-01 090-130 Orange 340 kg 27 mm 12.65 kg/mm 1/2 x 89 4
Spring Isolators
Rubber Isolators
5.6
44.5
44.5
60.5
8.64
98.55
85.9
139.7
14.2
104.9
63.5
6.35
73.2
RD2 RD3
Part
Number
Type
Color
Code Max Load,
kg
Deflection, mm Qty
99S502-01 RD2 Green 172 12.7 4
• Compatible with 030-045
Part
Number
Type
Color
Code Max Load,
kg
Deflection, mm Qty
99S502-02 RD3 Green 340 12.7 4
• Compatible with 060-150
