1.
PREPARATION AND REMOVAL, CONT’D
F.
Remove the six plastic nuts (three on each side)
holding the rear plastic panel of the trunk
G.
Remove the rear panel by first pulling up slightly
and then out in order to release the two spring
clips underneath.
Fig. 1-g
Fig. 1-h
Fig. 1-i
THREE PER
SIDE
PULL UP
SLIGHTLY TO
SEPARATE
HERE
