2.
FUEL PUMP VOLTAGE BOOSTER MOUNTING
A.
Position the mounting box into the approximate
location shown and mark the four mounting cor-
ners for drilling
B.
Drill the four mounting holes with a 1/8” drill
C.
Mount the FPVB unit using the supplied #10 sheet
metal screws.
Fig. 2-a
Fig. 2-b
DRILL WITH
1/8" DRILL
