4.
FINAL ASSEMBLY
A.
Connect the plug from the FPVB unit to the plug
of the installed harness.
B.
Using a 10mm socket or wrench, reattach the
negative OEM terminal to the battery.
C.
Replace the remaining car trim items in the
reverse order in which they were removed.
Fig. 4-a
Fig. 4-b
Fig. 4-c
