Vortech Cog Drive Upgrade for 2010-2011 Camaro - Manual (Page 9)

DP/N: 007123v1.0
© 2010 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured.
11FEB2010 50MM COG UPGRADE
1
1. PREPARATION AND REMOVAL
A. Unplug the connector from the MAF sensor.
B. Remove the discharge piping from the passenger
side intercooler up pipe to the throttle body.
C. Remove the existing serpentine supercharger belt
by loosening the spring tensioner with a ½” drive
breaker bar or ratchet.
Fig. 1-a
Fig. 1-b
