11FEB2010 50MM COG UPGRADE
3
1.
PREPARATION AND REMOVAL, CONT’D
E.
Remove the fixed idler from the front mounting
plate and replace with M10X1.5X55mm bolt and
washer.
Fig. 1-f
Fig. 1-g
