Vortech 1999 & 2001 Ford 4.6L Mustang Cobra - Manual (Page 9)

P/N: 8N020-060
© 2001 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured.
26APR01 V1.0 (4V Maxflow PwrClr(8N020-060).qxd)
1
1. Preparation and Removal
A. Disconnect and remove the battery (if located in
the factory position, the battery will need to be
relocated to the trunk).
B. Remove the supercharger discharge tube and
bypass valve assembly.
C. Remove the belt, supercharger and bracket.
D. Disconnect line from the air inlet that connects to
the valve cover vent.
E. If you are returning the supercharger assembly to
Vortech for a pulley change, remove the super-
charger from the bracket.
NOTE: Temporarily cap oil feed and oil drain to
protect your engine from foreign particles.
* Ignore these steps if the kit is being originally installed
onto the vehicle with the supercharger kit at the same
time. Refer to the supercharger kit instruction manual.
