Vortech 1999 & 2001 Ford 4.6L Mustang Cobra - Manual (Page 7)

P/N: 8N020-060
© 2001Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured.
08AUG01 V1.1(4V Maxflow PwrClr(8N020-060V1.1).qxd)
vii
Vortech Maxflow © Power Cooler ©
Part No. 8N301-050
1999 Ford 4.6 Mustang Cobra (4 Valve)
PARTS LIST
IMPORTANT: Before beginning installation, verify that all parts are included in the kit.
Report any shortages or damaged parts immediately.
Air/Water Aftercooler Assembly (8N201-060)
Water Cooler Assembly (8N106-030)
PART NUMBER DESCRIPTION QUANTITY
8N101-060 Welded Core Assy “99 4.6 4V 1
7R002-048 #48 goldenseal Hose Clamp 1
7P500-078 1/2NPT x 3/4 Hose Fit 2
7S350-301 Reducer, 3.50-3.00 1
008341 Power Cooler Decal 1
PART NUMBER DESCRIPTION QUANTITY
8N006-010 Water Cooler 1
7P500-026 90° Brass Fittings 2
8N010-050 Mounting Tabs 2
7E010-075 #12 x 3/4 HXHD Sheet Metal 4
7J010-001 #10 Flat Washer 4
7A250-075 1/4-20 x 3/4 SHCS 5
7F250-021 1/4-20 Nylock 5
7J250-001 1/4” Flat Washer 10
Water Pump Assembly (8N107-020)
PART NUMBER DESCRIPTION QUANTITY
5W001-011 14-16 GA Eyelet 1
5W001-012 18-22 GA Butt Connector 1
5W018-010 18 GA Wire Red (99”) 8.25’
5W001-019 12 GA Butt Connector 2
5W001-014 Fuse Holder 1
5W001-015 Fuse Blade Style 1
5W001-002 Fuse Tap 1
5W001-040 12-10 GA Female Slide 1
8F001-402 Pump, Water 1
7E010-075 #12 x 3/4” Sheet Metal Screw 2
7J010-001 #10 Flat Washer 2
7U133-060 3/4” x 90° Hose Elbow 1
7R003-027 Adel Clamp 1
5W001-024 Mini ATC Fuse Tap 1
5W001-025 18-22 GA Mini Female Slide 1
Water Tank Assembly (8N105-030)
PART NUMBER DESCRIPTION QUANTITY
8N105-010 Water Tank w/Fittings 1
7U038-000 3/4” Heater Hose (228”) 19’
7R007-001 Plastic Double Grip Clamps 7
7R003-016 15/16” Adel Clamps 3
7E010-075 #12 x 3/4 HXHD 3
7J010-001 #10 Flat Washer 3
7U100-044 Nylon Tie Wraps 4” 16
7U100-066 Nylon Tie Wraps 11” 6
Support Components
PART NUMBER DESCRIPTION QUANTITY
2A036-325 S/C Pulley, 3.25” 6-Groove 1
4FR012-030 Duct Discharge B 1
